(H-TEMP-C010) Polyimide-Polyimide
August 7, 2018
August 7, 2018
Show all


Technical Details

Conductor Annealed Bare Copper/Tinned Plated Copper/Silver Plated Copper/ Nickel Plate Copper
Conductor Type Solid wire / Flexible
Conductor Size 0.50/0.75/1.0/1.5/2.5 or variant as per customer specifications
Insulation Fiber Glass Insulation with high temperature varnish
Color By different colour thread
Outer Sheath Fiber Glass Insulation with high temperature varnish
Voltage Grade 300V / 600 V / 1100 V
Tested Voltage
  • 1500 V for 300 Voltage Grade
  • 2000 V for 600 Voltage Grade
  • 3000 V for 1000 Voltage Grade
Temperature Range -72 Deg C to 550 Deg C


  • Used around Blast furnace
  • Industrial & Commercial Heating Equipments
  • High Temperature appliances
  • Used in industrial area where resistance to high heat , abrasion, chemical, flame and hot material spills is required
  • Used in various industries such as Smelters, Glass & ceramic plants, Factories, Foundries, Rolling mills, Chemical industries, Steel & sponge iron plant etc & many more



  • Excellence Heat Resistance Properties
  • Suitable for High temperature zone area
  • Excellent chemical & abrasion resistance
  • Enhance thermal & Flame Retardant properties
  • Optional external SS metal covering for better mechanical protection
  • Halogen Free & low smoke
  • flame retardant and self-extinguishing acc. to IEC 60332-1
  • Temperature range up to 550 Deg C
  • Outer colour thread on metal braiding available for identification
