(SENSOFLEX 1100) High temperature yarn-High temperature yarn

Technical Details

Design Standard

ANSI MC 96.1 , IEC 60584.3 & ASTM E230/77

Conductor

K type original conductor & N type original conductor

Conductor Type

 Solid wire / Multistrand

No of Pair

Single Pair

Conductor Size

AWG 32 AWG to 14 AWG or Variant as per customer specifications

Insulation

High temperature yarn Insulation

Core Identification

Customer specifications

Outer Sheath

High temperature yarn

Outer Colour

Customer specifications

Accuracy

As per ANSI MC 96.1 / IEC 60584.3

Temperature Range

Up to 1100 Deg C

Categories: ,

Applications:

  • Metal Production
  • Heat treatment
  • Brick & Tile kiln
  • Industry plant, power station, refineries, petrochemical plants etc.
  • In Laboratory for calibration of high temperature furnaces
  • In Defence, Aerospace, Pharma, Fertilizer, Glass , Steel & Sponge, Cement, Nuclear & many more sectors.

Features:

  • Continues use up to 800 Deg C
  • Single exposure up to 1000 Deg C
  • Excellent Heat resistance
  • Better Flexibility
  • Flame retardant
  • Excellent Heat resistance
  • Chemical resistance

Notes

  • This wires are not water resistance, oil resistance & moisture resistance
  • For use in dry condition
  • Lower dielectric strength
  • Used for fixed installation only
  • Multiple use of this wire reduces its life & lower the strength
